FORGINGS:

Open Die Forgings:

Open Die Forging: Open die forging involves the shaping of heated metal parts between a top die attached to a ram and a bottom die attached to a hammer anvil or press bed. Metal parts are worked above their recrystallization temperatures-ranging from 1900°F to 2400°F for steel-and gradually shaped into the desired configuration through the skillful hammering or pressing of the work piece.

While impression or closed die forging confines the metal in dies, open die forging is distinguished by the fact that the metal is never completely confined or restrained in the dies. Most open die forgings are produced on flat dies. However, round swaging dies, V-dies, mandrels, pins and loose tools are also used depending on the desired part configuration and its size.

Although the open die forging process is often associated with larger, simpler-shaped parts such as bars, blanks, rings, hollows or spindles, in fact it can be considered the ultimate option in "custom-designed" metal components. High-strength, long-life parts optimized in terms of both mechanical properties and structural integrity are today produced in sizes that range from a few pounds to hundreds of tons in weight. In addition, advanced forge shops now offer shapes that were never before thought capable of being produced by the open die forging process.

Open Die Forgings

Size :     Up to 1600 Dia.

Weight :     0.5 Kgs. to 2500 Kgs.

Our Specialisation in following Material :

Carbon Steel :     A-105, A-350 LF2, [NACE + HIC] etc.

Alloy Steel :     F-5, F-9, F-11, F-22, F-91, etc.

Stainless Steel :     304, 304L, 316, 316L, 317L, 321, 347, 347H etc.

Duplex SS :     F51, F55

Products :     Tube Sheets, Rings, Valve Bodies, Discs, Shafts, Barred Tees, Blocks Special Flanges, Nozzles,
                         Long Weldnecks, Reducing Flage etc.

Dimension :     As per customer drawings.

Closed Die Forging :

Closed Die Forging : Closed Die Forging is a forging process in which dies move towards each other and covers the workpiece in whole or in part. The heated raw material, which is approximately the shape or size of the final forged part, is placed in the bottom die. The shape of the forging is incorporated in the top or bottom die as a negative image. Coming from above, the impact of the top die on the raw material forms it into the required forged form.
